ELISA Kit for Claudin 5 (CLDN5)

AWAL; BEC1; CPETRL1; TMVCF; Transmembrane Protein Deleted In Velocardiofacial Syndrome; Transmembrane protein deleted in VCFS


This assay has high sensitivity and excellent specificity for detection of Claudin 5 (CLDN5).
No significant cross-reactivity or interference between Claudin 5 (CLDN5) and analogues was observed.


Intra-assay Precision (Precision within an assay): 3 samples with low, middle and high level Claudin 5 (CLDN5) were tested 20 times on one plate, respectively.
Inter-assay Precision (Precision between assays): 3 samples with low, middle and high level Claudin 5 (CLDN5) were tested on 3 different plates, 8 replicates in each plate.
CV(%) = SD/meanX100
Intra-Assay: CV<10%
Inter-Assay: CV<12%


The stability of kit is determined by the loss rate of activity. The loss rate of this kit is less than 5% within the expiration date under appropriate storage condition.
To minimize extra influence on the performance, operation procedures and lab conditions, especially room temperature, air humidity, incubator temperature should be strictly controlled. It is also strongly suggested that the whole assay is performed by the same operator from the beginning to the end.

Reagents and materials provided

Reagents Quantity Reagents Quantity
Pre-coated, ready to use 96-well strip plate 1 Plate sealer for 96 wells 4
Standard 2 Standard Diluent 1×20mL
Detection Reagent A 1×120µL Assay Diluent A 1×12mL
Detection Reagent B 1×120µL Assay Diluent B 1×12mL
TMB Substrate 1×9mL Stop Solution 1×6mL
Wash Buffer (30 × concentrate) 1×20mL Instruction manual 1

Assay procedure summary

1. Prepare all reagents, samples and standards;
2. Add 100µL standard or sample to each well. Incubate 1 hours at 37°C;
3. Aspirate and add 100µL prepared Detection Reagent A. Incubate 1 hour at 37°C;
4. Aspirate and wash 3 times;
5. Add 100µL prepared Detection Reagent B. Incubate 30 minutes at 37°C;
6. Aspirate and wash 5 times;
7. Add 90µL Substrate Solution. Incubate 10-20 minutes at 37°C;
8. Add 50µL Stop Solution. Read at 450nm immediately.



Magazine Citations
ALLERGY ASTHMA & IMMUNOLOGY RESEARCH The Impact of the Endothelial Tight Junction Protein, Claudin-5, on the Clinical Profiles of Patients With COPD Pubmed:30088372
Catalog No. Related products for research use of Rattus norvegicus (Rat) Organism species Applications (RESEARCH USE ONLY!)
RPF295Ra01 Recombinant Claudin 5 (CLDN5) Positive Control; Immunogen; SDS-PAGE; WB.
PAF295Ra01 Polyclonal Antibody to Claudin 5 (CLDN5) WB; IHC; ICC; IP.
MAF295Ra21 Monoclonal Antibody to Claudin 5 (CLDN5) WB; IHC; ICC; IP.
SEF295Ra ELISA Kit for Claudin 5 (CLDN5) Enzyme-linked immunosorbent assay for Antigen Detection.
