Active Macrophage Inflammatory Protein 3 Beta (MIP3b)

CCL19; CKb11; ELC; MIP3-B; SCYA19; Chemokine C-C-Motif Ligand 19; Beta Chemokine Exodus-3; CK Beta-11; EBI1-Ligand Chemokine; Small Inducible Cytokine Subfamily A19

ACTIVITY TEST

Macrophage Inflammatory Protein 3 Beta (MIP3b) is a small cytokine belonging to the CC chemokine family that is also known as EBI1 ligand chemokine (ELC) and Chemokine C-C motif ligand 19 (CCL19). This chemokine elicits its effects on its target cells by binding to the chemokine receptor chemokine receptor CCR7. It attracts certain cells of the immune system, including dendritic cells and antigen-engaged B cells, CCR7 central-memory T-Cells. Thus, chemotaxis assay used 24-well microchemotaxis system was undertaken to detect the chemotactic effect of recombinant human MIP3b on the Jurkat cell line. Briefly, Jurkat cells were seeded into the upper chambers (150μL cell suspension,106 cells/mL in RPMI 1640 with FBS free) and MIP3b (0.01ng/mL, 0.1ng/mL, 1ng/mL, 10ng/mL, 100ng/mL and 1000ng/mL diluted separately in serum free RPMI 1640) was added in lower chamber with a polycarbonate filter (8μm pore size) used to separate the two compartments. After incubation at 37℃ with 5% CO2 for 3h, the filter was removed, then cells in low chamber were observed by inverted microscope at low magnification (×100) and the number of migrated cells were counted at high magnification (×400) randomly (five fields for each filter). Result shows MIP3b is able to induce migration of Jurkat cells. The migrated Jurkat cells in low chamber at low magnification (×100) were shown in Figure 1. Five fields of each chamber were randomly chosen, and the migrated cells were counted at high magnification (×400). Statistical results were shown in Figure 2. The optimum chemotaxis of recombinant human MIP3b occurs at 0.1-1ng/mL.
(A) Jurkat cells were seeded into the upper chambers and serum free RPMI 1640 with 0.1ng/mL MIP3b was added in lower chamber, then cells in lower chamber were observed at low magnification (×100) after incubation for 3h;
(B) Jurkat cells were seeded into the upper chambers and serum free RPMI 1640 without MIP3b was added in lower chamber, then cells in lower chamber were observed at low magnification (×100) after incubation for 3h.
Figure. The chemotactic effect of recombinant human MIP3b on Jurkat cells.

Figure. The chemotactic effect of recombinant human MIP3b on Jurkat cells.

USAGE

Reconstitute in 20mM Tris, 150mM NaCl (PH8.0) to a concentration of 0.1-1.0 mg/mL. Do not vortex.

STORAGE

Avoid repeated freeze/thaw cycles. Store at 2-8°C for one month. Aliquot and store at -80°C for 12 months.

STABILITY

The thermal stability is described by the loss rate. The loss rate was determined by accelerated thermal degradation test, that is, incubate the protein at 37°C for 48h, and no obvious degradation and precipitation were observed. The loss rate is less than 5% within the expiration date under appropriate storage condition.

GIVEAWAYS

INCREMENT SERVICES

Magazine Citations
BMC Veterinary Research MIP-3beta/CCL19 is associated with the intrathecal invasion of mononuclear cells in neuroinflammatory and non-neuroinflammatory CNS diseases in dogs Pubmed:25016392
Brain, Behavior, and Immunity Plasma inflammatory biomarkers for Huntington’s disease patients and mouse model Pubmed:25266150
Brain, Behavior, and Immunity Plasma inflammatory biomarkers for Huntington’s disease patients and mouse model PubMed: 25266150
类风湿关节炎血清中CCL19 和CCL21 的表达水平与肺间质病变的关系 :
Catalog No. Related products for research use of Homo sapiens (Human) Organism species Applications (RESEARCH USE ONLY!)
RPA096Hu01 Recombinant Macrophage Inflammatory Protein 3 Beta (MIP3b) Positive Control; Immunogen; SDS-PAGE; WB.
APA096Hu01 Active Macrophage Inflammatory Protein 3 Beta (MIP3b) Cell culture; Activity Assays.
PAA096Hu01 Polyclonal Antibody to Macrophage Inflammatory Protein 3 Beta (MIP3b) WB; IHC; ICC; IP.
LAA096Hu71 Biotin-Linked Polyclonal Antibody to Macrophage Inflammatory Protein 3 Beta (MIP3b) WB; IHC; ICC.
MAA096Hu22 Monoclonal Antibody to Macrophage Inflammatory Protein 3 Beta (MIP3b) WB; IHC; ICC; IP.
SEA096Hu ELISA Kit for Macrophage Inflammatory Protein 3 Beta (MIP3b) Enzyme-linked immunosorbent assay for Antigen Detection.
LMA096Hu Multiplex Assay Kit for Macrophage Inflammatory Protein 3 Beta (MIP3b) ,etc. by FLIA (Flow Luminescence Immunoassay) FLIA Kit for Antigen Detection.
